Carbon steel plate/sheet

PRODUCT FEATURES

Carbon steel is an alloy with carbon and iron, with carbon content up to 2.1% by weight. The increase in the carbon percentage will raise steel’s hardness and strength, but it will be less ductile. Carbon steel has good properties in hardness and strength, and it is less expensive than other steels.

THE MAIN PARAMETER

Application	JIS	ASTM	SAE
Commercial Quality	G3131 SPHC	A569 A635 A659 A1011 CS Type A, B, C	1006~1025
Drawing Quality	G3131 SPHD	-	1006-1010
Deep Drawing Quality	G3131 SPHE	A622 A1011 DS Type A, B	1006~1010
General Structure (T.S. < 490 N/mm₂)	G3101 SS330 SS400 G3106 SM400A G3132 SPHT1 SPHT2 SPHT3	A36 A283 GR.C A570 GR.30~40 A1001 SS GR.30~40	1010~1025
General Structure (T.S. ≧ 490 N/mm₂)	G3101 SS490 G3106 SM490A SM490A SM490YA G3132 SPH4	A570 GR.45~50 A607 GR.45~70 A1011 SS GR.45, 50 A1011 HSLAS GR.45~70	J1392 050X

Available Size

Carbon Steel Hot Rolled Coil / Strip
	Thickness (mm)	Mill Edge Width (mm)	Cut Edge Width (mm)	Coil Inside Diameter (mm)
Coil	1.50~6.50	720~1860		762
Coil	6.51~10.00	850~1500		762
Strip	1.50~6.50		30~720	762

Carbon Steel Hot Rolled Plate / Sheet
	Thickness (mm)	Mill Edge Width (mm)	Length (mm)
Plate	6.00~150	500~4000	1200~18000
Sheet	1.50~5.99	50~1845	760~6100

Application

Carbon hot rolled steel sheets and plates are used in the welding and construction sectors such as railroad tracks, construction equipment, boom cranes, agriculture equipment and heavy vehicle frames. By varying the percentage in carbon steel, it is possible to produce steel with a variety of different qualities. In general, higher carbon content in steel makes steel harder, brittler and less ductile.
